Sensor: 384x288px @ 12µm
Objective Lens (Focal Length): 35 mm
Detection Distance: 1800 m
SENSOR
Type: "VOx Uncooled Focal Plane Arrays"
Resolution, pixels: 384 × 288 px
Pixel pitch, µm: 12µm
Frame rate, Hz: 50 Hz
NETD: <20mK
THERMAL OPTICS
Objective lens: F1.0
Focal Length: 35mm
Magnification: 3.5x - 28x
Min. Focusing Distance: 3.5m
Field of view: 7.5°x5.6° (H × V)°
Optical Camera
Image Sensor: Progressive Scan CMOS
Resolution: 2560 x 1440px
Focal Length: 31mm
Aperture: F1.2
Min. Focusing Distance: 3m
Magnification: 2.9x to 23.3x
Field of view: 13.9° × 7.8° (H × V)°
Smart IR: Yes
Viewing range in darkness: 400m
Laser Range Finder
Max Measuring range: 1000m
Safety Class for laser: Class 1
Measurement accuracy: ± 1m
DISPLAY
Type: 12.5mm, OLED
Resolution, Pixels: 1920 x 1080
Thermal Colour Palettes: Black Hot, White Hot, Red Hot, Fusion
Optical Colour Palettes: Full colour Day time, Black and White Night time
Video Recorder
Build in memory, Gb: 64 Gb
Image Capture: Yes
Video Record: Yes
Audio recording: Yes
Additional Features
Zoom Pro: Yes
Standby Mode: Yes
Picture in Picture: Yes
GPS & Compass: Yes
Image Pro Mode: Yes
Hot Tracking: Yes
Wi-Fi Hotspot: Yes
HIKMICRO Connect App support: Yes
Environmental
Degree of protection, IP code: IP67
Dust protection: Protected against dust ingress
Water protection: Protected against temporary submersion in water
Operating temperature range: -30 °C to 55 °C
WEIGHT & SIZE
Dimensions, mm: 138 mm x 68 mm x 212 mm
Interpupillary Adj.: 60mm to 70mm
Weight, kg: 780 g
POWER SUPPLY
Battery type: 2x 18650 Removable battery
Operating time on battery (Wi-Fi & Hot tracking disabled): 6 Hours continuous running
Compatible with USB Powerbank: Yes
Charging interface: External charger (Supplied)
Warranty Period Main Unit: 3 Years
